The Fameca MTag Voltage Detecor supplied by Hylec are designed for “proving dead”, making sure that nominal voltage is actually absent on a circuit in an HV distribution system between 1 kV and 69 kV. This device will detect any nominal voltage on overhead lines and stations. It will avoid detecting most induced voltages in order to allow grounding operations.
Advatages:
-
Optimised indication that can be understood clearly in all working conditions:
• The visual indication is visible in all usual working environments, in sunlight or fog, with a wide angle of visibility and from the side thanks to an optic ring.
• The 100 dB sound signal is designed to remains audible even in traffic or strong wind, thanks to its acoustic “horn”.
-
Direct access to the battery and sealed electronics compartment. When the battery is replaced, this design prevents the following:
• Accidental interchange of housing or circuitry;
• Damage to electronic circuits;
• Humidity ingress into the device when the battery is replaced outdoors.
Specifications:
- Possible choice of AC voltage range from 1-4kV to 69kV
- Complies with IEC 61243-1 Voltage Detector Capacitive Type
- To be used for voltages exceeding 1kV AC
- Network Frequency: 50 & 60 Hz
- Permanent standy-by status with automatic wake up function
- Self test function
- Designed for Indoor & Outdoor use
- Operating Temperature: -25°C to 55°C
- Humidity: 96 max
- Housing: Polycarbonate (Yellow)
- 9V Battery operated
