Ins. Stick 1.0m w/sunrise head

More Views

Ins. Stick 1.0m w/sunrise head

PART NUMBER: HSPXV1100U

FAMECA's operating insulating stick 1.0m length supplied by Hylec are made from high quality foam-cored tubes that can be used on high voltage applications. With a universal (sunrise) end fitting, you can easily attach different adaptors to apply i.e. Earthing, Contact and Non-contact votlage detectors, Disconnect hooks etc.

Details

FAMECA's operating sticks supplied by Hylec are made from high quality foam-cored tubes that can be used on high voltage applications. With a universal (sunrise) end fitting, you can easily attach different adaptors to apply i.e. Earthing, Contact and Non-contact votlage detectors, Disconnect hooks etc.

Hylec has the capability to manufacture different lengths or with different end fittings as per the customers requirements.

FAMECA has been known for over 70 years as a manufacturer of composite insulating tubes. FAMECA's long experience in the field has led it to develop a foam-cored tube that meets the requirements of international standards IEC 60855 and ASTM F711. This process guarantees; perfect homogeneity of the foam inside the insulating tube & unfailing tightness thank to a foam-resin-glass fibre interface which fills the open cells on the surface of the foam, mazimising the level of insulation by preventing any humidity from penetrating at all.

Specifications:

  • Fibreglass composite tube, foam-filled
  • Diameter: Ø 32mm
  • Dielectric strenght 100kV per 300mm
  • Complies to IEC 60855 standard
  • Colour: High visibility yellow
  • Standard Lengths: 1.2m, 1.5m, 1.8m. Other lengths available upon request

Additional Information

Extra Information No
Send inquiry? No
ebs_extended_descr No

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please, log in or register

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Ins. Stick 1.0m w/sunrise head

AUD

Ex GST $331.98
